LAUNCH KIT
Limited release to select customers.
Our team is granting early access for exclusive partners to test our new 360° collision avoidance system as we complete internal testing and validation before full release.
Be the first to fly 360 with Casia!
Casia 360 Quick Specs
Launch Kit
- Field of View
- Horizontal: 360°, 40° overlap (5 cameras)
- Vertical: 50°
- Size (ea)
- Casia Module: 77mm (W) x 110mm (L) x 36mm (D)
- Camera: 60mm (W) x 60mm (L) x 105mm (D)
- Weight (ea)
- Casia Modules: 2x at 291g , 582 total (with enclosure)
- Casia Modules: 2x at 167g, 334 total (without enclosure)
- Cameras: 5x at 191g, 955g total
- Power
- 20W Nominal, 30W Peak
Casia 360 is built to meet the current draft ASTM DAA Performance standard risk ratios, ultimately giving customers the most effective DAA solution for commercial drone applications.
Launch Kits Available
Casia 360
Datasheet
The datasheet provides technical specification information on the Casia 360 Launch Kit.
Revision: V1.0
Last Updated: 2020-03-13
CAD Model
CAD models allow you to perform a virtual integration of the Casia device and confirm the effects of size and weight in software.
Revision: V3.0
Last Updated: 2019-12-13
